British Type Hose Clamp

    KEY PERFORMANCE

     British type hose clamp using both carbon steel and stainless steel materials

     Two kinds of material steel strip width and thickness of 9.7 mm , 11.7 mm and 0.8 mm

     Standard:BS5315:1991

APPLICATIONS

● This kind of clamp wildly used  in the automobile industry,shipbuilding industry,machinery industry in various equipment oil, water, gaspipeline.They are ideal accessories for various hoses'connecting and fastening


货号 Item NO.
LTYS  with  welded Housing
(英式点焊喉箍)
LTYS with rivetd Housing
(英式铆头喉箍)
LTYS with Tube Housing
(英式挂头喉箍)
Part No.Size
(inch)
Size
(mm)
Band Width
(mm)
Part No.Size
(inch)
Size
(mm)
Band Width
(mm)
Size
(inch)
Size
(mm)
Band Width
(mm)
OOO1/29-139.7OOO1/29-139.71/29-139.7
MOO5/813-169.7MOO5/813-169.75/813-169.7
OO3/413-199.7OO3/413-199.73/413-199.7
O7/816-229.7/11.7O7/816-229.7/11.7/12.77/816-229.7/11.7
OX 119-259.7/11.7OX 119-259.7/11.7/12.7119-259.7/11.7
1A 1.1/722-299.7/11.71A 1.1/722-299.7/11.7/12.71.1/722-299.7/11.7
11.1/225-3511.711.1/225-3511.7/12.71.1/225-3511.7
1X 1.5/728-4111.71X 1.5/728-4111.7/12.71.5/728-4111.7
2A 231-4811.72A 231-4811.7/12.7231-4811.7
22.1/438-5411.722.1/438-5411.7/12.72.1/438-5411.7
2X2.1/244-6011.72X2.1/244-6011.7/12.72.1/244-6011.7
32.3/450-7011.732.3/450-7011.7/12.72.3/450-7011.7
3X 3.1/760-8011.73X 3.1/760-8011.7/12.73.1/760-8011.7
43.1/270-9011.743.1/270-9011.7/12.73.1/270-9011.7
4X3.8/980-10211.74X3.8/980-10211.7/12.73.8/980-10211.7
54.1/395-11511.754.1/395-11511.7/12.74.1/395-11511.7
65.1/8104-12711.765.1/8104-12711.7/12.75.1/8104-12711.7
6X5.8/9127-14611.76X5.8/9127-14611.7/12.75.8/9127-14611.7
76.2/7140-16011.776.2/7140-16011.7/12.76.2/7140-16011.7
7X7.1/9160-18011.77X7.1/9160-18011.7/12.77.1/9160-18011.7
87.7/8180-20011.787.7/8180-200/8.1/16175-20511.7
/9.1/9210-23011.7/9.1/9210-230/9.2/16200-23111.7
/9.5/6230-25011.7/9.5/6230-250/10.1/16226-25611.7
/11260-28011.7/11260-280/11.2/16251-28211.7











材质
Material
钢带
Band
箍头
Housing
螺丝
Screw
建议安装扭力
Suggested Install Torque
W1Zinc Plated SteelZinc Plated Steel
Zinc Plated Steel∅≦29   3.0Nm
∅≦40   4.8Nm
∅≦44   5.2Nm
W2AISI  SS301/SS304AISI  SS301/SS304Zinc Plated Steel
W4AISI  SS301/SS304AISI  SS301/SS304AISI  SS301/SS304
