SAE J1527 Fuel Pipe for Ships (Certified by CCS)

Mar. 12, 2020


SAE J1527 marine fuel pipe is mainly used to refuel marine vessels, and serves as a connection between port gas stations and vessels.



1.SAE J1527 and ISO7840 marine fuel lines, category A1, can be used for related operations of marine gasoline storage tanks, and can also be used for refueling and unloading of marine luxury yachts. This product complies with the requirements of the "US Coast Guard" and "International Marine Certification Agency" for Class A1 operations.

①Working temperature: -17 ° C to 46 ° C

② Hose structure:

Inner layer: Black nitrile synthetic rubber RMA classification grade Oil resistance A grade (high oil resistance)

Reinforcement: fiber weave

Outer layer: black synthetic rubber

③Common specifications: 1/4 ", 5/16", 3/8 ", 1/2", 5/8 ", 3/4", 1 ", other specifications can be customized



2.SAE J1527 Type A2 Fire Retardant marine fuel suction and discharge hose, with flame retardant performance, used for refueling and unloading of marine luxury yachts.

①Working temperature: -18 ° C to 46 ° C

② Hose structure:

Inner layer: A grade of RMA classification of black nitrile synthetic rubber (high oil resistance)

Reinforcement: Multi-layer fiber braid with wire spiral

Outer layer: grey synthetic rubber

③Common specifications: 3/4 "-2-3 / 8", other specifications can be customized



3.SAE J1527 Type B2 Non-Fire Retardant marine fuel suction and discharge hose, non-flammable, used for refueling and unloading of marine luxury yachts

①Working temperature: -18 ° C to 46 ° C

② Hose structure:

Inner layer: A grade of RMA classification of black nitrile synthetic rubber (high oil resistance)

Reinforcement: Multi-layer fiber braid with wire spiral

Outer layer: grey synthetic rubber

③Common specifications: 3/4 "-2-3 / 8", other specifications can be customized



4.SAE J1527 yacht inlet and outlet pipes are used for fuel oil inlet and outlet of marine gasoline tanks for marine yachts. The fence structure can meet the requirements of the EPA's low-permeability level A1-15 marine fuel line. Fire-resistant outer layer can provide USCG Class A for 2.5 minutes

① Operating temperature: -29 ° C to 82 ° C

② Hose structure:

Inner layer: black synthetic rubber

Reinforcement layer: multilayer fiber weave

Outer layer: Nitrile synthetic rubber

③Common specifications: 1/4 ", 5/16", 3/8 ", 1/2", 5/8 ", 3/4", 1 ", other specifications can be customized



Yatai Hose has its own technical research and development team, has strict standards and perfect operating procedures in terms of product quality control, and our products have CCS Classification Society certification, which can provide you with better services and get more Opportunity.

For more information, please consult our sales and technical team.
