NO.1 Smooth PTFE Hose
I.D：1mm ~ 50mm
Thk：0.5mm ~ 2mm
O.D：3mm ~ 54mm
100% PTFE without adding any recycled materials
Temp：-70°C ~ +260°C
Features: chemical resistance, weather resistance, non-flammability,
very low friction, UV resistance, aging resistance
Application: heat exchangers, transportation of chemical raw materials, pharmaceutical intermediates, and corrosive substances;
Transportation of high and low temperature liquids and gases;
Insulation and heat insulation protection of various electronic and communication components
NO.2 Corrugated PTFE Hose
I.D：6.5mm ~ 50mm
O.D：10.6m ~ 59.5mm
100% PTFE without adding any recycled materials
Temp：-70°C ~ +260°C
Features: effectively absorb the vibration, noise and thermal expansion of the piping system;
Solve the slight deviation caused by the pipeline connection and eliminate the residual stress of the pipeline;
Suitable for repeated exercise in high temperature areas, good fatigue resistance;
Good flexibility, high temperature resistance, corrosion resistance;
Application: Suitable for low friction bearings, bushings, rollers and pulleys;
It can be used for sealing and cryogenic parts, and is also a very important engineering plastic in the aerospace industry
NO.3 Anti-static PTFE Hose
Performance: high temperature resistance, low temperature resistance, and withstand low temperature without hardening
Dielectric strength: can withstand voltages in the range of 50 volts to 120 kilovolts
Low friction coefficient: the friction coefficient is only 0.1, and the static and dynamic coefficients are almost the same
Static Control: Prevents any form of charge buildup
Chemical resistance: resistant to all kinds of corrosion and water repellent, also highly inert to chemicals
Applications: chemical liquid handling, transport of flammable liquids, static load coating industry, food industry
