KEY PERFORMANCE
● Germany type hose clamp using both carbon steel and stainless steel materials
● big torque and take up little space, easy to assembly in narrow space
● Standard：DIN3017
● Press on both side could protect the hose, Inside convex concave design can fixed the hose better and avoid the hose off or back
| 带宽9mm货号1tem DO. | 紧固范围 Range mm Q675 | 紧固范围 Rangemm DIN3017 | S mm | 带宽12mm货号1temno | 紧固范围 Rangemn Q675 | 紧固范围 Rangemm DIN3017 | S mm | |||
| WIW2 | W4 W5 | WI W2 | W4 W5 | |||||||
| LTDS/09B0812 | LTDS/09Q0812 | 8-12 | 8-1 | 23 | / | / | / | / | / | |
| LTDS/09B1016 | LTDS/09Q1016 | 10-16 | 10-16 | 23 | / | / | / | / | / | |
| LTDS09B1222 | LTDS/09Q1222 | 12-22 | 12-22 | 23 | LTDS/12B1220 | LTDS/12Q1220 | 12-22 | 12-22 16-27 | 23 | |
| LTDS/09B1627 | LTDS/09Q1627 | 16-27 | 16-27 | 23 | LTDS/12B1625 | LTDS/12Q1625 | I 23-35 30-45 32-50 | 23 | ||
| LTDS/09B2032 | LTDS09Q2032 | 23-35 | 20-32 | 23 | LTDS/12B2032 | LTD5/12Q2032 | 20-32 25-40 | 23 | ||
| LTDS/09B2540 | LTDS/09Q2540 | 25-40 | 25-40 | 26 | LTDS/12B2540 | LTDS/12Q2540 | 26 | |||
| LTDS/09B3250 | LTDS/09Q3250 | 32-50 | 30-45 | 26 | LTDS/12B3250 | LTDS/12Q3250 | 30-45 | 26 | ||
| 35-50 | 26 | 35-50 | 26 | |||||||
| LTDS/09B4060 | LTDS/09Q4060 | 40-60 | 40-60 | 26 | LTDS/12B4060 | LTDS/12Q4060 | 40-60 | 40-60 | 26 | |
| LTDS/09B5070 | LTDS/09Q5070 | 50-70 | 50-70 | 26 | LTDS/12B5070 | LTDS/12Q5070 | 50-70 | 50-70 | 26 | |
| LTDS/09B6080 | LTDS/09Q6080 | 60-80 | 60-80 | 26 | LTDS/12B6080 | LTDS/12Q6080 | 60-80 | 60-80 | 26 | |
| LTDS/09B7090 | LTDS/09Q7090 | 70-90 | 70-90 | 26 | LTDS/12B7090 | LTDS/12Q7090 | 70-90 | 20-90 | 29 | |
| LTDS/0O9B80100 | LTDS/09Q80100 | 80-100 | 80-100 | 26 | LTDS/12B80100 | LTDS/12Q80100 | 80-100 | 80-100 | 29 | |
| LTDS/09B9011 | LTDS/09Q90110 | 90-110 | 90-110 | 26 | LTDS/12B90110 | LTDS/12Q90110 | 90-110 | 90-110 | 29 | |
| LTDS/09B100120 | LTDS/09Q100120 | 100-120 | 100-120 | 26 | LTDS/12B100120 | LTDS/2Q10020 | 100-120 | 100-120 | 31 | |
| LTDS/O9B10130 | LTDS/09Q110130 | 110-130 | 110-130 | 26 | LTDS/12B100130 | LTDS/12Q100130 | 110-130 | 110-130 | 31 | |
| LTDS/09B120140 | LTDS/09Q120140 | 120-140 | 120-140 | 26 | LTDS/12B120140 | LTDS/12Q120140 | 120-140 | 120- 140 | 31 | |
| LTDS/09B130150 | LTDS/09Q130150 | 130-150 | 130-150 | 26 | LTDS/12B130150 | LTDS/12Q130150 | 130-150 | 130-150 | 31 | |
| LTDS/09B140160 | LTDS/09Q140160 | 140-160 | 140-160 | 26 | LTDS/12B140160 | LTDS/12Q140160 | 140-160 | 140-160 | 31 | |
| 材质 Material | 钢帶 Band | 箍头 Housing | 螺丝 Screw | 建议安装扭力 Suggested Install Torque | ||||||
| W1 | Zinc Plated Steel | Zinc Plated Steel | Zinc Plated | ∅≦25 Band(9mm) 3.0 Nm Band(12mm) 3.4 Nm ∅≧27 Band(9mm) 3.4 Nm Band(12mm) 3.8Nm | ||||||
| W2 | AISI SS430/SS200/SS304 | AISI SS430/SS200/SS304 | Zinc Plated | |||||||
| W4 | AISISS304 | AISISS304 | AIS1 SS304 | ∅≦25 Band(9mm) 4.0 Nm Band(12mm) 4.9 Nm ∅≧27 Band(9mm) 4.5 Nm Band(12mm) 4.8Nm | ||||||
| W5 | AISISS316 | AISI5S316 | AISI SS316 | |||||||
